Eversolo DAC-Z10 Unveiled: Precision Engineering for Authentic Sound

Experience uncompromised purity and warmth with Eversolo DAC-Z10’s precision-engineered audio excellence.

A New Benchmark in Hi-Fi Audio

When a product promises to “rediscover the true sound,” you expect it to deliver on every front. That’s exactly what Eversolo DAC-Z10, a high-resolution DAC and headphone amplifier, aims for. Launched in late 2025, this device is a true testament to precision engineering, combining cutting-edge technology with a passionate dedication to musical authenticity.

The DAC-Z10 isn't just another DAC—it’s a finely crafted musical instrument engineered to reconstruct every signal with warmth, clarity, and nuance. From its architecture to its user interface, it’s designed to immerse audiophiles in a soundstage that feels alive and organic.

Fully Isolated Architecture for Pure Sound

At the heart of the DAC-Z10 lies Eversolo’s proprietary Fully Isolated Architecture (FIATM), a design philosophy that physically and electrically separates digital and analog domains. This isolation is critical to minimize interference and preserve the purity of your music signal.

What truly fascinated me here is the internal layout: three custom linear power supplies dedicated to left channel, right channel, and system circuitry, each carefully isolated. Imagine this as having individual power plants for every major component, ensuring that nothing contaminates the delicate audio processing.

Dual AKM Modules: Separate Paths for Stereo Purity

One of the DAC-Z10’s standout features is its dual AKM decoding modules. Each stereo channel is managed by its own pair of AK4191 and AK4499 chips. This means from the moment your digital tracks enter the DAC, left and right signals remain fully independent, eliminating channel crosstalk.

Not only does this enhance separation, but it also improves dynamic range and resolution. Thanks to AKM’s signature Velvet Sound technology, the DAC delivers a sonic presentation that’s both razor-sharp and silky smooth. Whether playing DSD512 or 768 kHz/32-bit PCM files, the DAC-Z10 boasts ultra-low distortion (THD+N of 0.00008%) and a dynamic range of 130 dB—numbers that clearly back up the promise of live-performance energy and presence.

R2R Resistor Network Volume Control: Analog Precision in a Digital World

Volume control often gets overlooked, but the DAC-Z10 treats it as a vital piece of the audio puzzle. Unlike conventional digital volume controls that can introduce quantization distortion, this unit uses a high-precision R2R resistor network for each channel separately.

What does that mean for you? Every turn of the volume knob results in pristine analog-level adjustments. The sound remains phase-aligned and pure from the softest whispers to ear-shattering crescendos. This is the kind of thoughtful engineering that audiophiles crave—holding onto every nuance without compromise.

Balanced Preamplifier and Connectivity Galore

The DAC-Z10 doubles as a powerful preamplifier, equipped with fully balanced XLR and RCA inputs/outputs and delivering +10 dB analog gain. This makes it more than just a DAC—it can directly drive power amps or active speakers with ease.

On the connectivity front, the DAC-Z10 is a marvel: USB Audio in, dual coaxial and optical inputs, IIS, AES/EBU, and HDMI ARC input support. The USB port uses a multi-core audio processor capable of DSD512 Native and PCM 768 kHz/32-bit lossless transmission. Every input is electrically isolated to eliminate ground loop noise—meaning your signal stays as pure as intended no matter the source.

Precision Clocking: The Secret to Sonic Depth

Clock systems are often the unsung heroes of any high-end audio device. The DAC-Z10 features the Eversolo Precision Core™ , a sophisticated clocking system crafted from an OCXO temperature-controlled crystal oscillator, PLL technology, and FPGA clock reconstruction.

This trio works in harmony to provide femtosecond-level clock accuracy. The temperature-controlled OCXO crystal eliminates environmental frequency shifts, PLL suppresses jitter, and the FPGA reconstructs the clock and IIS data with surgical precision. The result? Greater phase accuracy, natural transients, and a depth in imaging that truly brings music to life.

For those with advanced master clocks, the DAC-Z10 accepts external 10 MHz and 25 MHz clock inputs with selectable impedance options (50 Ω and 75 Ω). This flexibility allows seamless integration into professional studios or sophisticated home systems, elevating the listening experience to new heights.

Built for Headphone Lovers and Home Theaters Alike

The headphone amplifier module includes a 6.35 mm output that automatically detects the impedance of connected headphones and adjusts gain accordingly. When switched to high gain, it pumps out 1 watt at 16 Ω or 32 Ω, capable of driving even demanding planar magnetic headphones without breaking a sweat. Experience this by exploring Eversolo DAC-Z10 headphone amplifier options.

For home theater enthusiasts, HDMI ARC and eARC support enable direct audio feed from TVs and entertainment systems, extending the DAC’s excellent sound quality beyond music to movies and games. Plus, a built-in Qualcomm QCC5125 Bluetooth module supports high-resolution wireless streaming—a nod to modern convenience without sacrificing fidelity.

User Experience: Intuitive Touchscreen and Remote Control

The DAC-Z10 sports an 8.8-inch IPS touchscreen with electromagnetic shielding for interference-free operation. Its interface is refreshingly straightforward, ditching complicated menus in favor of intuitive controls. Multiple VU meters and dynamic spectrum displays offer a retro or modern visual flair, and customizable knob colors add a touch of personal style.

Even better, the included Eversolo Control App lets you operate the DAC remotely from your smartphone or tablet. Adjust volume, switch inputs, and fine-tune settings from the comfort of your couch—because high-end audio should be as effortless as it is exquisite.

A Philosophy of Sound: Precision Meets Emotion

The DAC-Z10 embodies a complete philosophy of sound—precision, warmth, purity, and balance.

What truly sets the DAC-Z10 apart is its embodiment of a sound philosophy: a perfect blend of precision, warmth, purity, and balance. It’s a reminder that digital music doesn’t have to be sterile or mechanical. Instead, with the right engineering, it can resonate with soul and emotion.

If you’re hungry for an audio experience that honors the intricacies of music, Eversolo’s latest offering invites you to rediscover sound in its purest form.

Pricing and Availability

The Eversolo DAC-Z10 carries a suggested retail price of approximately $1,980 USD / €1,980 EUR. The official release date is approaching soon, so keep an eye out for availability.

FAQ

• What is the Fully Isolated Architecture in the DAC-Z10?
  It’s a design that physically separates digital and analog components to minimize interference, resulting in a cleaner, purer sound signal.
• How does the dual AKM DAC module improve sound quality?
  Each stereo channel has its own AKM chip set, keeping left and right signals independent, eliminating crosstalk, and boosting dynamic range and resolution.
• Can the DAC-Z10 be used as a preamplifier?
  Yes, it includes a fully balanced preamplifier with XLR and RCA connections and can directly drive power amplifiers or active speakers.
• What are the clocking features of the DAC-Z10?
  It uses an OCXO temperature-controlled crystal oscillator combined with PLL and FPGA technologies to ensure ultra-low jitter and precise timing.
• Does it support wireless streaming?
  Yes, it has a built-in Qualcomm QCC5125 Bluetooth module that supports high-resolution audio streaming.
